Framex-PS 60

Cold Sliding PVC System

Framex PS60 is the optimal solution for outfitting window openings in unheated spaces.

Frame Installation Depth
60 mm

Sealing System
2 Seals, Felt

Filling Thickness
20 mm

Number of Sashes in the
Structure 2, 3, 4, 6

Previous slide

Next slide

Technical specifications

System Type:	Sliding
Frame Installation Depth:	60 mm
Sash Installation Depth:	43 mm
Number of Tracks:	2
Visible Profile Part (Frame + Sash):	113 mm
Threshold Height:	56 mm
Filling Thickness:	20 mm
Number of Chambers in Profile (Frame/Sash):	3/2
Sealing System:	2 Seals, Felts
Water Tightness:	6А
Air Permeability:	2
Min Sash Size:	500x1500 mm
Max Sash Sizes:	1000х1850 mm
Max Width of Construction:	4000 mm
Max Sash Weight:	120 kg
Number of Sashes in Construction:	2, 3, 4, 6
Handle Type:	Push
External Locking:	None

PVC profiles of the Framex PS 60 system are made from PVC-U polyvinyl chloride in accordance with the requirements of DSTU B V.2.7-130. The wall thickness of the profiles complies with Class B according to DIN EN 12608 / Class B according to DSTU B V.2.7-130.

Application

Framex PS60 can be used for glazing balconies and loggias, outfitting greenhouses, garden pavilions, winter gardens, and more.

Advantages of Framex PS 60

The PS 60 system provides protection for cold spaces from atmospheric factors such as wind, dust, rain, and noise. It allows for comfortable conditions on an outdoor terrace and separation from external atmospheric factors.

Unlike hinged constructions, it saves space and increases usable area,
which is particularly important where space is limited,
allowing light to enter the room unobstructed
due to its design.
